- 8 Channels Bi-Directional(2 Way) Line-Level balanced audio XLR (female to male, male to Female). 20 Km on 1 core Single-mode Fiber or 500 meters on 1 core Multi-mode Fiber. not directly support Mic-Level Audio.
- So It can not directly with the Microphone, if the Audio is from Microphone, the user need other devices like DJ controller/ Audio MIxer which has Amprifier function to work with our Extender. if the microphone is Dynamic type and need to directly connect with our Extender, please select our this item.
- Supports 16-bit digitally encoded broadcast quality balanced audio; 1 U Chassis rack-mount installation. Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required;
- LED indicators are provided to instantly monitor the system operating status.
BY-XLR-117 includes 8 Ch Bi-directional balanced audio fiber optic transmitter and receiver, which supports 8 Channels 2 ways 16-bit digitally encoded broadcast quality balanced audio over 1 core multi-mode or single-mode optical fiberr (multi-mode up to 500 Meters or single-mode optical fiber up to 20 Kilometers). it can be stand-alone or rack-mount installation
Or shop on Amazon with worldwide Shipment (Free & Expedited)
Output Power: -10~ -5dBm
Supported Optic fiber: 50/125u multi-mode，62.5/125u multi-mode，9/125u single-mode
Rx sensitivity: -25dBm
Optical connector: 1 x LC, or 1 x SC, 1 x FC, 1 x ST
Distance: 0~500 Meters (MMF) / 0~20 Kilometers (SMF)
Number of Channels: 8 Input + 8 Output
Input Connector: XLR（female）
Output Connector: XLR（male）
Input / Output Impedance: 10K Ohm
Input capacitance LINE inputs: 10 pF
Max input/output voltage: +4 dBu (1.228 Volts). if over the limit, the audio distortion will appear.
Frequency Response: 20 Hz～24kHz @±3dB
Sample Rates From: 48kHz
SNR: > 80dB
Electrical & Mechanical:
Power Adapter: AC 90V~240V
Power Consumption: < 8W
Installation: 1.5U rack-mount chassis (the image has the details)
Shipping Weight: (include Transmitter & Receiver ) 7kg
Operating Temperature: -20°C ~ +75°C
Storage Temperature: -40°C ~ +85°C
Relative Humidity: 0% ~ 95% (non-condensing)
MTBF: >100,000 hours
Rental, Staging, Theater, Stadiums, Theme Parks, Broadcast/Studio, CCTV audio and Professional AV etc
1. 1 x transmitter with optical module.
2. 1 x receiver with optical module.
3. 1 x Manual
Once order received, we will worldwide deliver by DHL Express for about 1~2 week delivery.
BY-XLR-117 (4 Ch 2 Way over 1 Single-mode Fiber)
BY-XLR-117MF (4 Ch 2 Way over 1 Multi-mode Fiber)
